六角濕膜梳 K0003236M201?? ?20 - 370μm

部件編號    范圍    厚度值
K0003236M201    20 - 370µm    20, 30, 40, 50, 60, 70, 80, 90, 100, 110, 120, 130, 150, 170, 190, 210, 230, 250, 270, 290, 310, 330, 350, 370µm
K0003236M202    25 - 2000µm    25, 50, 75, 100, 125, 150, 175, 200, 225, 250, 275, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 950, 1000, 1100, 1200, 1300, 1400, 1500, 1600, 1700, 1800, 1900, 2000µm
B112----1B    25 - 3000µm    25, 50, 75, 100, 125, 150, 175, 200, 225, 250, 275, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 1000, 1100, 1200, 1400, 1600, 1800, 2000, 2200, 2400, 2600, 2800, 3000µm
K0US3236M203    0.5 - 15mils    0.5, 0.75, 1.0, 1.25, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5, 6, 6.5, 7, 8, 9, 10, 11, 12, 13, 14, 15mils
K0US3236M204    1 - 80mils    1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30, 32, 34, 36, 38, 40, 42, 44, 46, 48, 50, 55, 60, 65, 70, 75, 80mils
B112----2B    1 - 120mils    1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30, 32, 34, 36, 38, 40, 45, 50, 55, 60, 70, 80, 90, 100, 110, 120mils
尺寸和重量    Elcometer 3236M201
M203    53 x 50 x 1mm (2.09 x 1.97 x 0.04”)
10g (0.35oz)
    Elcometer 3236M202
M204    77 x 90 x 1mm (2.95 x 3.54 x 0.04”)
 22g (0.77oz)
    Elcometer 112    75 x 65 x 1mm (2.95 x 2.54 x 0.04”)
 20g (0.7oz)
證書類型    校準證書：為固定校準設備出具的證書，上面顯示示值和溯源
認可證書：可為固定校準設備出具的證書，由獨立的校準實驗室出具的完全UKAS可溯的證書
包裝清單    濕膜梳、包裝袋和操作手冊
